CNC & Manual Rotary Arm Tube Bending – (mandrel supported)
Round Tube: 3" OD x .188 Max. – Up to 24" Radius
Square Tube: 2 1/2" OD x .083 Max.
Rectangular Tube:
1 1/2" x 3" OD x .148 Max. (Easy Way)
1 1/2" x 2 1/2" OD x .120 Max. (Hard Way)
Pipe: 2" Sch.80
Compression / Ram Bending
Round Tube: 1 1/2" OD x .065 Mild Steel
Square Tube: 1/2" x .065
Pipe: 1/2" Sch.40
Solid Rod: 1/2" OD
Roll Bending
Round Tube: 2 1/2" OD x .065
Pipe: 2" Sch.40
Square Tube: 2" x 2" OD x .125
Rectangular Tube:
3" x 1 1/2" OD x .250 (Easy Way)
2 1/2" x 1 1/2" OD x .125 (Hard Way)
Draw Bending
Round Pipe: 4" Sch.40
Cutting
Band Saw: 6" Sch. 80 Pipe
Radial Arm (Aluminum): 2" OD Max.
Manual Cold Saw: 3" OD x .120
Automatic Cold Saw: 3" OD x .120
De-Burring
Burrmaster – Wire Brush Deburring
Planetary Tube Polishing
Single and Double Headed Chamfering
Threading
NPT Pipe Threads: 4" Sch. 40 Pipe
Tubing: 1" OD x .065
Tube End Forming
Reducing – Ram & Segment: 3" OD x .065 Max. / 6" Forming Stroke
Expanding – Ram: 2" OD x .065 Max. / 6" Forming Stroke
Expanding – Segment: 1 1/2" to 3" OD
Flaring: 3 1/6" to 3" OD – 37° & 45°
Beading – Roll Formed: 3" OD x .065
Beading – Compression: 2" OD x .065
Chamfering / Squaring: 3" OD
Notching: 3" OD Max.
Punching, Trimming, Flattening, Slotting, & Notching
50 Ton Press Capacity
Hydraulic & Pneumatic Presses
Welding
(5) MIG – (1) TIG – (1) Induction Brazing – (1) Silver Soldering
(5) Large Welding Bays
